| Business Type | Manufacturer, Exporter, Supplier, Retailer |
| Material | Stainless Steel |
| Country of Origin | India |
| Driven Type | Hydraulic, Electric |
| Click to view more | |
Product Details
Automatic Grade
Automatic
Capacity
100 Tph
Power
1-3kw
Voltage
440V
Warranty
1year
A ROLL CRUSHER is a type of crushing machine that is used in various industries to reduce the size of material (suchas ore, coal, limestone, and similar materials) by squeezing them between two revolving cylinders with the gap between them narrowing down towards the discharge end.
Features :
- High output of good product shape
- Low maintenance
- Fully automated
- Fast and easy adjustment
- Hydraulic control
- Compact Lubrication system
Size Chart
| Model | Feed Opening (MMXMM) | Maximum Feed Size (in mm/inch) | Adjusting Range of Opening (in MM) | Crushing Cpacity (in T.P.H) | Shaft (RPM) | Recommended Motor H.P. (1440RPM) | Weight Approx (in Tons) |
| CMR-3018 | 750X450 | 12MM/1/2" | 03/05/26 | 08/12/26 | 90 | 20 HP-2 Nos. | 6 |
| CMR-3024 | 750X600 | 12MM/1/2" | 03/05/26 | 12/15/26 | 90 | 25 HP-2 Nos. | 7 |
| CMR-4020 | 1000X500 | 20MM/3/4" | 05/07/26 | 35-40 | 85 | 40 HP-2 Nos. | 12 |
| CMR-4830 | 1200X750 | 25MM/1" | 06/08/26 | 50-55 | 80 | 100 HP-2 Nos. | 25 |
